Aruba AP-515 Q9H63A WiFi 6 Campus AP for 4.8Gbps Enterprise Speed

The Aruba AP-515 (Q9H63A) is a high-performance, enterprise-grade Wi-Fi 6 (802.11ax) campus access point designed for high-density environments like schools, retail stores, and large offices.

Product Overview

The Aruba 510 Series (AP-515) delivers high-performance connectivity for organizations facing growing numbers of mobile and IoT requirements. By utilizing Wi-Fi 6 (802.11ax), the AP-515 provides a maximum aggregate data rate of 5.4 Gbps, ensuring seamless video conferencing, large file transfers, and uninterrupted cloud application use.

Key to its performance is the 4x4:4 MU-MIMO on the 5GHz band, which allows the AP to serve multiple clients simultaneously without performance degradation. Additionally, it features integrated Bluetooth 5 and Zigbee radios to simplify the deployment and management of IoT location services and asset tracking. With Aruba’s ClientMatch technology, the AP-515 automatically directs devices to the best available radio for optimized efficiency.

Technical Specifications

Key Features

• Incredible Throughput: Delivers up to 4.8 Gbps on the 5GHz band, making it ideal for bandwidth-intensive enterprise applications.

• AI-Powered ClientMatch: Automatically groups Wi-Fi 6 capable devices onto available radios to maximize network capacity and eliminate "sticky clients."

• IoT Ready: Built-in Bluetooth and Zigbee support allow for easy integration of smart building sensors and location-based asset tracking.

• Energy Efficiency: Features Aruba Intelligent Power Monitoring (IPM), which allows the AP to operate even when power budgets are limited by intelligently disabling certain features.

• Enterprise Security: Supports WPA3 and Enhanced Open, providing robust encryption and protecting guest networks without requiring complex passwords.

• OFDMA & Target Wake Time: Increases multi-user efficiency and extends the battery life of connected IoT and mobile devices.
